Aramid Fiber Fabric
Aramid fiber fabric is made of aramid fiber at different pattern such as plain weave, twill weave, and satin weave. The aramid fiber varies in different density such as 200D, 400D, 600D, 800D, 1000D, 1500D, and 3000D.
Features
Introduction:
Aramid fiber fabric is made of aramid fiber at different pattern such as plain weave, twill weave, and satin weave. The aramid fiber varies in different density such as 200D, 400D, 600D, 800D, 1000D, 1500D, and 3000D.
Features:
impact resistant,
dynamic load fatigue resistant,
anti electrical conductivity
Application:
Aramid fiber fabric is used in recreation ≥ leisure products, automotive, aerospace, sports, medical equipment, electro mechanic equipment, etc.
Specification:
Basic weight: 100g, 160g, 200g, 300g, 450g in plain or twill with different input aramid yarn.
Roll width: upto 3000mm
# | Item | Thickness (mm) | Basic wt (g/m²) | Input Yarn | density (count/10mm) | Weaving Method | Width | |
warp | weft | (mm) | ||||||
1 | AF50 | 0.08 | 50 | 200D | 200D | 13.5 x 13.5 | plain | 100 - 3000 |
2 | AF100 | 0.15 | 100 | 600D | 600D | 8.0 x 8.0 | plain | 100 - 3000 |
3 | AF140 | 0.22 | 140 | 1000D | 1000D | 6.0 x 6.0 | plain | 100 - 3000 |
4 | AF160 | 0.24 | 160 | 1000D | 1000D | 7.0 x 7.0 | plain / twill | 100 - 3000 |
5 | AF200 | 0.26 | 200 | 1000D | 1000D | 9.0 x 9.0 | plain / twill | 100 - 3000 |
6 | AF200 | 0.26 | 200 | 1500D | 1500D | 6.0 x 6.0 | plain | 100 - 3000 |
7 | AF300 | 0.40 | 300 | 1500D | 1500D | 4.5 x 4.5 | plain | 100 - 3000 |
8 | AF450 | 0.70 | 450 | 3000D | 3000D | 6.5 x 6.5 | plain | 100 - 3000 |
